EDV21A

60GHz in-situ physical sign monitoring sensor

easy to use
powerful performance
cost-effective

Product Introduction

EDV21A adopts cutting-edge 60G millimeter wave sensing technology to detect millimeter level micro movements in the chest cavity in real time, intelligently monitor sleep stages, intelligently identify abnormal breathing or heart rate, long-term displacement and other events, support timely alarms, and safeguard user health and safety.

Specification

Operating voltage of the whole machine

12V DC
Operating current of the whole machine

150mA average operating current 250mA maximum operating current
Standby power consumption of the whole machine

Average < 1.8W Maximum ≤ 3W @ 12DC
Communication Methods

HTTP
Detection range

0.05m-0.6m
On/Off Detection Time

Typically stays on for 1-2s and stays off for 5-45s.
Measurement Range

Respiratory rate range: 0–30 breaths per minute Heart rate range: 0–105 beats per minute
Last Updated

Interval not exceeding 10s 1 to 10s Currently set to 1s

Application Scenarios

Meeting Room

Hotel

Smart Appliance

Smart Business
