EDQ12KA

24 GHz millimeter-wave band, centimeter-level high-precision sensing

Ultra-narrow size exterior
better directional consistency
Micro-motion sensing

Product Introduction

24GHz millimeter-wave band with centimeter-level high-precision sensing; Single transmitter with dual receiver antenna design precisely defines sensing boundaries, immune to external interference; High-sensitivity breathing detection instantly senses presence within the sensing zone; Supports serial port online firmware upgrades; Specialized software algorithms enable blocking of passing targets.

Specification

Frequency band

24-24.25GHz
Input voltage

5-8V
Output voltage

3.3V
Power consumption

0.2W
Sensing distance

5m adjustable
Hanging height

Side-mounted 1.2m
Product size

38*7mm

Application Scenarios

Mirror

Advertising Machine

Smart Appliance
